Castrol ON Immersion Cooling Fluid DC 20
01736 757002Castrol ON Immersion Cooling Fluid DC 20
Castrol ON Immersion Cooling Fluid DC 20 is a synthetic hydrocarbon based dielectric coolant.
Immersion Cooling Fluid DC20 is a single phase coolant designed for use in electrical/electronic cooling systems. It has excellent flow properties and thermal properties. This product also provides a superior oxidative stability, excellent dielectric properties, low temperature properties and excellent hydrolytic stability.
Castrol ON Immersion Cooling Fluid DC 15 Advantages:
- Low viscosity fluid providing excellent flow properties
- Excellent thermal properties.
- Superior oxidative stability, low temperature properties and excellent hydrolytic stability.
- Excellent dielectric properties.
- Compatible with most commercially available elastomers.
| Name | Method | Units | ON Immersion Cooling Fluid DC 20 |
| Viscosity, Kinematic @ 0°C | ASTM D445 | mm²/s | 19.8 |
| Viscosity, Kinematic @ 20°C | ASTM D445 | mm²/s | 9.2 |
| Viscosity, Kinematic @ 40°C | ASTM D445 | mm²/s | 5.1 |
| Viscosity, Kinematic @ 100°C | ASTM D445 | mm²/s | 1.7 |
|
Density @ 15,6 °C / 60 °F |
ASTM D3321 | kg/m3 | 797 |
|
Pour Point |
ISO 3016 | °C / °F | -57/-70 |
|
Thermal conductivity @ 40 °C / 104 °F |
ASTM D7896 | W/mK | 0.135 |
|
Specific heat capacity @ 40 °C / 104 °F |
ASTM E1296 | kJ/kgK | 2.2 |
|
Electrical conductivity @ 25 °C / 77 °F |
DIN 51111 | pS/m | <35 |
|
Dielectric strength @ 25 °C / 77 °F |
IEC 60156 | kV/mm | >14 |
| Dielectric breakdown voltage @ 25 °C / 77 °F | IEC 60156 | kV/mm | >35 |
| Dielectric constant @ 25 °C / 77 °F | ASTM D924 | 2.06 | |
| Flash Point, COC | ASTM D92 | °C / °F | 169/336 |
| Fire Point, COC | ASTM D92 | °C / °F | 191/376 |
Health & Safety:
Please refer to the relevant health and safety data sheet, a copy of which is freely available to all our customers.
Storage:
All packages should be stored under cover. Where outside storage is unavoidable, drums should be laid horizontally to avoid the possible ingress of water and the obliteration of drum markings. Products should not be stored above 60°C or exposed to hot sun or freezing conditions.
